CW-AP / CW-AP-WFormulation materials
Hydrophobic Silica Aerogel Powder and Particles
Nanoporous SiO2 aerogel raw material for coatings, composite fillers and functional modification systems.
- Specific surface areaCW-AP powder
- 400-800 m²/g
- Bulk densityCW-AP powder
- 60-100 kg/m³
- Slurry solidsCW-AP-W only
- 20-25%
Overview
Hydrophobic silica aerogel powder is intended for formulators developing low-density coatings, composites and functional fillers. The waterborne slurry route is intended where a pre-dispersed aqueous input is preferable.
Powder and slurry are different product forms. Their figures are presented separately and should not be transferred to a finished coating or composite without formulation-level verification.
- Dry powder
- Select for dispersion trials in the intended coating or composite formulation.
- Waterborne slurry
- Use the pre-dispersed aqueous form where addition order, shear and viscosity can be verified in a lab trial.
Typical applications: Waterborne industrial coatings, Thermal coating formulas, Composite fillers.
Specifications and test basis
CW-AP powder
| Property | Value | Basis |
|---|---|---|
| Specific surface area | 400-800 m²/g | Supplied brochure table; powder grade; GB/T 19587 listed. |
| Bulk density | 60-100 kg/m³ | Supplied brochure table; powder grade. |
| Pore diameter / porosity | 20-50 nm / 90-95% | Supplied product summary; powder grade. |
CW-AP-W waterborne slurry
| Property | Value | Basis |
|---|---|---|
| Waterborne slurry | 20-25% solids; 15,000-40,000 cP; 0.020-0.025 W/(m·K) at 25 °C | Supplied brochure table; slurry only; final formulation performance is not implied. |
Handling and selection limits
Handling / storage
- Use dust-control and mixing procedures appropriate for fine powders.
- For slurry systems, establish shear, addition order and viscosity with a lab trial before scale-up.
Selection limits
- Not a finished insulation system or a substitute for formulation testing.
- Waterborne slurry data do not establish the performance of a customer's coating after adding binders, pigments or fillers.
Source documents
| Document | Applicable grade | Availability |
|---|---|---|
| Supplied English product brochure: silica aerogel powder and waterborne slurry tables. | CW-AP / CW-AP-W | Request documentation |
Last reviewed: 09 August 2026.
Product FAQ
Can powder be added directly to a waterborne coating?
A formulation trial is required to confirm dispersion, viscosity, wetting and the final cured-coating performance.
Does the slurry figure apply to my final coating?
No. It describes the supplied slurry only; the finished coating must be evaluated in its own formulation and film build.
Discuss your application
Share the substrate, temperature and required test standard for a grade-specific review.
